Ø Online Maintenance Patented Technology
(1) Supports online maintenance function and prevents disconnection; applies a special algorithm to continuously interact and communicate with the base station activating the device’s online status to ensure online stability;
(2) Re-establishes the dialing mechanism, so that even if a disconnection occurs, it will go online within tens of milliseconds, a time so short that it is imperceptible to humans;
(3) Restarts the communication module to establish a new connection;
(4） Performs a full-device power-off restart, eliminating the need for manual on-site power unplugging and reducing enterprise maintenance costs.
Ø Network Backup
- The device supports local area network WIFI and wide area network 3G/4G/5G wireless network functions;
- It supports switching between wired and wireless networks to achieve the network backup function;
- It supports dual-SIM card network backup (optional);
Ø Full network access
- 5G cellular access, supporting SA and NSA networking;
- 4G cellular access, CAT1/4/CAT6 networking, backward compatible with 3G/2G networks;
Ø Support large-scale deployment
In Industrial IoT applications, facing the networking and control of thousands of terminal devices, you need to deploy tens of thousands of routers Caimao gateways feature web management and SNMP management capabilities, enabling remote configuration, remote upgrades, routing OTA upgrades, and user application OTA upgrades, effectively helping you solve device management and issues;
Ø Customizable Python development platform
Supports a secondary development platform based on the Python language, allowing users to implement customized APP applications according to their own business needs; gateway supports Linux OpenWRT system development;
Ø Support for multiple industrial protocols
To be compatible with the numerous industrial controller devices on the market, the gateway supports the following industrial protocols: Modbus TCP, Mod RTU, EtherNet/IP, Modbus TCP Slave, etc.;
Ø Supports multiple industrial cloud ecosystems
Caimao gateways support the following industrial cloud platforms: Alibaba Cloud, Tencent Cloud, Power Cloud Platform, Amazon AWS, and IoT cloud platforms. To provide customers with more solutions, Caimao is committed to developing the industrial IoT cloud ecosystem;
Ø Comprehensive security features
(1) Supports VPN secure tunnel functions, including PPTP, L2TP, IPSEC, and OPENVPN, and supports multiple: TCP/IP, UDP, ICMP, etc.;
(2) Firewall functions such as DMZ isolation, virtual IP mapping, MAC-IP address binding, and WAN access restriction, with multiple security protection measures to ensure the network is not attacked from the outside;
(3) Supports security protection functions at multiple levels, including device user permission, network security, and data security;
Ø High Reliability Design
- Three-layer system protection: On the basis of the original two-level system protection (software protection built-in watchdog WDT protection), an additional level of system virtual man watch (VWM) detection and protection function is added. When there is a network anomaly or the system strong interference, the system will perform a complete reset, which is equivalent to a maintenance person unplugging the power on-site. This completely solves the industry trouble of needing to unplug power when system anomalies occur, ensuring system stability and reliability;
- High-speed processing CPU: Adopting a high-speed industrial-grade CPU, it can process protocol data conversions at higher speeds; it solves difficult industry problems such as “fake online”, “fake crash”, and “system downtime”;
- Excellent stable performance: It passed the 3000V electric shock test, making it particularly suitable for use in harsh industrial environments; the system has excellent EMC/EMI performance, and the system is and reliable; it has passed CE certification, FCC certification, ROHS certification, E-mark certification, 3C certification, CB certification, Moore high and low temperature test certification and EMC testing, etc.
