| Project | content |
| Network Interconnection | |
| Network access | APN、VPDN |
| Access authentication | CHAP/PAP/MS-CHAP/MS-CHAPV2 |
| Network standard | For details, see the radio parameters |
| LAN protocol | ARP、EtherNet |
| network protocol | |
| IP application | Ping, Traceroute, DHCP server/relay/client, DNS relay, dynamic domain name DDNS, Telnet, SSH, HTTPS, TFTP, FTP, SFTP |
| IP route | static route and dynamic route |
| Network security | |
| Firewall | Full-state packet inspection (SPI) and defense against denial-of-service (DoS) attacks |
| Filtering multicast/Ping packets, access control lists (ACLs) |
| NAT, PAT, DMZ, port mapping, virtual server |
| Multi-level user | user level management |
| AAA | Local authentication, Radius, Tacacs+, LDAP |
| data security | CA (can be automatically applied for), supporting SM1, SM2, SM3, and SM4 encryption algorithms |
| VPN | IPSec VPN、L2TP、PPTP、GRE、N2N、L2TP OVER IPSec、GRE OVER IPSec、EOIP、OPENVPN |
| hardware encryption (option) | Supports State Grid encryption, Southern Network encryption, and national encryption |
| Reliability | |
| backup function | VRRP, interface backup, dual SIM card backup (optional) |
| Online link detection | Online maintenance function, sending heartbeat packet detection, disconnection automatically connnect |
| Built-in watchdog | Equipment operation self-check technology, equipment operation failure self-repair |
| Wi-Fi (optional) | |
| Protocol standard | IEEE802.11ac/a/b/g |
| security features | Open system, shared key, WPA/WPA2 authentication,WEP/TKIP/AES encryption |
| Working mode | Working mode of the AP and client |
| network management | |
| configuration mode | Local or remote HTTPS, Telent, and SSH modes |
| Upgrading mode | Local or remote log output and log saving in case of power failure |
| SMS function (optional) | status query, configuration, and restart |
| On demand dialing | Data activation, SMS activation, and scheduled online/offline |
| Network management function | SNMP/power TR069 management |
| DM | Centralized management and batch configuration |
| DHCP | DHCP server and DHCP client,Port mapping SNAT/DNAT, DMZ host |
| Network diagnosis | Ping, Traceroute, and Sniffer (network packet capture tool) |
| software function | |
| software function (option) | Supports 5G, 4G, and 3G wireless communication. |
| Supports Ethernet to 5G/4G/3G wireless communication. |
| Supports Ethernet-to-WiFi communication. |
| Supports serial port/485 to 5G/4G/3G wireless communication; Supports serial port/485 to WiFi communication; Supports serial port/485 to Ethernet communication; |
| Supports DTU transparent transmission. Supports MQTT transparent transmission. |
| Supports the APN/VPDN network. |
| Supports the VXLAN function |
| The wired and 5G/4G/3G wireless links back up each other. WiFi and 5G, 4G, and 3G radio links work in active/standby mode |
| Supports online maintenance. Supports the DTU LAN port client heartbeat packet function |
| Supports wireless network frequency lock and card lock |
| Supports limiting the number of Wi-Fi connections and client isolation |
| Supports WiFi clones. (Up to 4 WiFi names, SSID name extension, each with an independent MAC address) |
| MAC and SN fixed |
| Access restriction is supported |
| Supports port alarms |
| Supports single Beidou positioning; Supports GPS positioning. Supports Beidou and GPS hybrid positioning (optional) |
| Wired, WiFi, and wireless links work in active/standby mode (optional) |
| Supports IP traffic distribution. (The IP data traffic from different sources or destinations is distributed to multiple network links, servers, or paths through specific technologies. The core purpose is to avoid congestion on a single path and improve network bandwidth utilization and stability.) (Optional) |
| Supports Wi-Fi client signal strength detection (optional) |
| Supports recording the online and offline time of users in wired, wireless, and WiFi (optional) |
| Supports TF card software encryption (optional) |
| The customer can customize the product log and product model (optional) |
| Supports centralized platform management, including remote parameter configuration, OTA upgrade, remote multimedia update (music, video, and ad playback), blacklist and whitelist management, traffic statistics, online statistics, network standard statistics, SMS authentication, WeChat authentication, WiFi authentication, traffic control, speed limit control, and Internet access restriction. Long-term, Internet access behavior control, WiFi probe, and multi-level user management (optional) |
| Development platform | |
| Supports multiple platforms (option) | Python development, realizing customized development for customers |
| Amazon AWS |
| Tencent Cloud |
| Power cloud platform |
| IoT cloud platforms such as Alibaba Cloud |
| industrial agreement | |
| Supports multiple industrial protocols (option) | Modbus TCP and Modbus TCP/RTU conversion |
| Modbus RTU |
| EtherNet/IP |
| Modbus TCP Slave |
| Supports MQTT |
| Sopport Ntrip Client、Ntrip Server |
| Power protocol (optional) | Supports the 101/104 protocol, 645 protocol, 61850 protocol, and TR069 protocol |
| Environmental protection agreement (optional) | HJ212-2005/2017 |
